TBS5927 Professional DVB-S2 Satellite TV Tuner USB Box

TBS 5927 PROFESSIONAL DVB-S2 SATELLITE TV TUNER USB BOX

The TBS5927 is a Professional level digital satellite TV Tuner box with USB 2.0 connection to PC. TBS5927 supports not only normal DVB-S2/DVB-S QPSK, 8PSK which is supported by normal satellite receivers, but also ACM, VCM, Multi Input Stream, 16APSK and 32APSK mode, Multiple Generic Stream, Combined Single Generic & Single TS, which most satellite receiving devices are unable to support. The built in hardware blind scan feature allows scanning of unknown satellite transponder with symbol rate as low as 200ksps, while most satellite receiving devices can receive no less than 1Msps symbol rate. With use of dedicated TBS tools, those special streams can be captured. Both Windows BDA driver and Linux driver are provided.

Benefits

• EUMETCast Compatibility
• DVB-S2/S Transponders Receiving
• CCM, VCM,ACM and Multi Input Stream Support
• Watch & record satellite TV/ radio programs onPC
• Wide range symbol rates support from 200Ksps to 45Msps
• High-speed Data download via Satellite
• Unicable/One Cable compatible
• Blindscan support
• High reliability

Technical Specification:

• Receiving Frequency
  950~2150 MHz Tuning Range
• Input level
  -69~-23dBm
• Demodulator
  Yes
• Symbol Rate
  DVB-S QPSK
  0.2~45Msps
  DVB-S2 QPSK/8PSK
  0.2~45Msps
  DVB-S2 CCM ACM VCM
  QPSK+1/4, 1/3, 2/5, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10
  8PSK+3/5, 2/3, 3/4, 5/6, 8/9, 9/10
  16APSK+2/3, 3/4, 4/5, 5/6, 8/9, 9/10
  32APSK+3/4, 4/5, 5/6, 8/9, 9/10
  DVB-S
  QPSK+1/2, 2/3, 3/4, 5/6, 7/8
• Data Burst & Tone Burst
  Supported
• DiSEqC2.X and Motor
  Supported
• Carrier Capture Range
  ±10MHz
• Applications
  Data receiving
  IPTV streaming
  Media monitoring
  Digital content distribution

Power consumption

• Input/Power 12V
• T emperature 0~60℃

System Requirements

• Windows 2000/XP/Vista/7/8/10 or Linux
• Available USB 2.0 Port
• Satellite Dish and LNB

Dimension

• TV tuner Boxsize 12 x 9 x 2cm
• Net weight 190g
• G ift Box Size 16 x 16 x 8cm
• Weight 615g

Package Contents

• 1 x TBS5927
• 1 x Power adapter
• 1 x USB cable
