TBS6281 DVB-T2 Dual Freeview HD PCI Express Card
Description
DISCONTINUED - SEE NEW 'SE' VERSION HERE
TBS6281 DVB-T2 DUAL FREEVIEW HD PCI EXPRESS CARD
The TBS6281, the successor of the TBS6280, is a dual tuner PCI-Express interface DVB-T2/T TV Tuner Card which supports watching or recording two different channels from two different frequencies simultaneously TBS 6281 can be used as a digital video recorder for recording digital terrestrial TV programs with full HDTV support. It also enables you to pause a live broadcast and continue from where you left with the Time-shifting function. This DVB T2 PC TV card is ready with windows BDA driver and Linux driver. It’s ideal for watching UK Freeview SD and HD channels on your PC. Please ensure you can receive the Digital Terrestrial Television (DVB-T, DVB-T2 Freeview) service in your region. You need to use a high-gain roof aerial to enable and enjoy reliable digital television reception throughout the UK. TBS6280 has one RF IN port, and one LOOP OUT port. The RF IN port is for connecting to antenna, while LOOP OUT port is for transmitting signal to another DVB-T2 receiver.
Specifications:
- Receiving Channel: VHF band and UHF band
- Channel Bandwidth: 6, 7, 8 MHz
- DVB-T2/ T modulation type: QPSK, 16QAM, 64QAM, 256QAM
- FFT mode: 1K, 2K, 4K, 8K, 16K, 32K
- Code rate: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 7/8
- Guard interval: 1/4, 1/8, 1/16, 1/32, 1/64, 1/128, 19/128, 19/256
- RF-Input Impedance 75Ω (IEC-DIN female)
- RF-Output Impedance 75Ω (IEC-DIN male)
System Requirements:
- Windows XP / Vista/ 7, Linux
- Pentium 4 2.0 GHz, Pentium M 1.3 GHz
- For HDTV: 2.6 GHz multi core processor
- Hard disk with min. 1 GB free capacity
- Sound and graphics card with support for DirectX 9 or higher
- Available PCI Express x1,x4, x8 or x16 slot
- CD/DVD drive for software installation
