| H618 |
| |
| CPU | Allwinner H618 Quad Core ARM Cortex A53 |
| GPU | G31 OPenGL ES3.2, Vulkan 1.1 Open CL 2.0 |
| Memory | DDR4：1GB (Option: 2GB) |
| Flash | eMMC：8GB (Option:16GB ) |
| WiFi | IEEE 802.11 b/g/n/a 2.4G/5.8G |
| Moudle | Plastic : Black Color |
| I/O | 1*HDMI | 4K*2K UHD Output, HDMI 2.0A |
| 1*AV OUT | 480i/576i standard definition output |
| 2*USB | 1* USB Host Port ,1*USB Device |
| 1*SPDIF | |
| 1*RJ45 | Ethernet Interface |
| 1*TF CARD | Support 4GB/8GB/16GB/32GB/64GB |
| Power | DC 5V/2A；LED indicator，Working ：Blue; Standby：Red |
| Software |
| OS | Android 10.0 |
| Video | • Supports video decoding up to 8K@22fps |
| • Supports multi-formats: |
| - H.265 Main10@L5.1 up to 8K@22fps |
| - VP9 Profile 2 up to 4K@30fps |
| - AVS2 JiZhun 10bit Profile up to 4K@60fps |
| - H.264 BP/MP/HP@L4.2 up to 4K@30fps |
| - H.263 BP up to 1080p@60fps |
| - MPEG-4 SP/ASP@L5 up to 1080p@60fps |
| - MPEG-2 MP/HL up to 1080p@60fps |
| - MPEG-1 MP/HL up to 1080p@60fps |
| - Xvid up to 1080p@60fps |
| - Sorenson Spark up to 1080p@60fps |
| - VP8 up to 1080p@60fps |
| - AVS/AVS+ JiZhun Profile up to 1080p@60fps |
| - WMV9/VC1 SP/MP/AP up to 1080p@60fps |
| - JPEG HFIF file format up to 45MPPS |
| H.264 BP/MP/HP |
| • H.264 supports I/P frame, and only supports single reference frame |
| • MJPEG/JPEG baseline |
| • Maximum 16-megapixel(4096 x 4096) resolution for H.264 encoding |
| • H.264 encoding capability: 1080p@60fps |
| • JPEG snapshot performance of 1080p@60fps independently |
| • Supports the constant bit rate(CBR)ariable bit rate(VBR) bit rate control mode, ranging from 256kbit/s to |
| 100Mbit/s |
| • Encoding of eight regions of interest(ROIs) |
| Audio | Supports MP3, AAC, WMA, RM, FLAC, Ogg |
| Built-in serial digital audio SPDIF/IEC958 input/output and PCM input/output |
| • Two DAC channels |
| • Supports 1 audio output interface (differential LINEOUTP/N or single-end LINEOUTL/LINEOUTR) |
| • One Audio HUB, supporting internal mixing function |
| • Embedded 3 I2S/PCM (I2S0 for extended audio codec, I2S2 for BT, I2S3 for digital power amplifier) |
| • Supports Left-justified, Right-justified, Standard I2S mode, PCM mode, and TDM mode |
| • I2S mode supports 8 channels, and 32-bit/192kbit sample rate |
| • I2S and TDM modes support maximum 16 channels, and 32-bit/96kbit sample rate |
| • One OWA OUT interface, supporting 16-/20-/24-bit inputs and outputs |
| • Integrated digital microphone(DMIC), supporting maximum 8 digital PDM microphones |
| Image | HD JPEG、BMP、GIF、PNG、TIF |
| Language | English French German Spanish Italian etc multilateral languages |
| Appliactions |
| Online | Browse all video websites,support Netflix,Hulu,Flixster, Youtube, etc. |
| Apps | Apps download freely form android market、amazon app store etc. |
| Medium | Local Media playback,Support HDD, U Disck ,TF Card . |
| Others | Support Email,office suit etc. |
| Support DLNA function |
| Support 2.4G wireless mouse/keyboard |
| Packing | Product dimension | 100*100*20(mm) |
| Qty per unit packing | 1pcs |
| Unit packing: (LxWxH) | 170*115*55(mm) |
| Unit packing (G.W.) | 0.36KG |
| Qty per export carton | 20PCS |
| Export carton (WxHxL) | 370*290*240 （mm） |
| Export carton (G.W.) | 7.5Kg |
